NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester
NOYAFA NF-810 Network Cable Tester

NOYAFA NF-810 Network Cable Tester

$42.00 $39.11
/
Shipping calculated at checkout.
  • 30-Days Money Back Guarantee
  • In stock, Fast Free Shipping
Black Friday 2024 Offer:
Buy more and save more
  • BUY OVER $300 for 10% OFF: Copy code BF300TEN
  • BUY OVER $600 for 11% OFF: Copy code BF600ELV
  • BUY OVER $1,000 for 12% OFF: Copy code BF1KTEW
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • Shop Pay
  • Union Pay
  • Visa

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

Features & Benefits

  • Multi Function - RJ11 Tracing / RJ45 Tracing / Electronic wire Tracing  / Wiremap/ Against 60V / PoE Testing / TEL Testing / Lighting / Earphone.
  • Multi Function Testing Mode - It supports to open, short, cross of lan cable, included STP cable.
  • PoE Switch Testing - It supports the power supply by switch. D1D2 lighting, it means the PIN I &2 supply power.
  • Wire Tracing - For RJ11/RJ15/Electronic cables.
  • Against DC60V - Say no for burning.
  • Telephone Line Status Detection - Polarity & Status Test (Idle, Rings, Conversation).
  • LED Lighting - It is easier to work in dark environment.
  • Earphone Function - It helps you to work well in a noise environment.
  • Certification - Passes RoHS, FCC, and CE compliance testing, and Noyafa is certified to the ISO 9001 standard.
  • 100% Affordable - Manufactured in China and a lot cheaper than competitor products with similar quality.

    model：NF-810

    Power specification：9Vlaminated battery

    Applicable network cable：CAT5 CAT6/telephone cable

    Interface withstand voltage：60V

    Interface type：RJ11/RJ45

    Wiremap functionMaximum working current：<70mA

    Switch to line：R.J45
    main interface + directlyconnected to the switch

    Scanning function：Yes

    Short circuit/channel test：Yes

    Signaltransmission format：Dual tone pulse

    Signaltransmission distance：≤1km

    Telephone line polarity state test：Yes

    Size：201*45*27(mm)

    Sensitivity adjustment：Yes

    POE switch test：Yes

    Tracking working current：≤40mA

    Wiremap functiont：Yes

    Headphone functiont：Yes

    LED lighting：Yes

    Size：125*28*45(mm)

    NOYAFA NF-810 Instruction

    NF-810 Multi Function Wire Tracker

    Cont / Scan / Test / Against DC60V PoE Scanning

    Main Functions

    RJ11 Tracing. RJ45 Tracing. Electronic Wire Tracing. Wiremap. Against 60V. PoE Testing. TEL Testing. Lighting. Earphone.

    Multi Function Testing Mode

    It supports to open, short, cross of LAN cable, included STP cable.

    PoE Switch Testing

    Identify which pins are providing power.

    Wire Tracing

    For RJ11 / RJ45 / Electronic Cables.

    Against DC 60V

    Say no for burnning.

    Telephone Line Status Detection

    Polarity & Status Test (Idle, Rings, Conversation)

    LED Lighting

    It is easier to work in dark environment.

    Earphone Function

    It helps you to work well in a noise enviroment.
