Name: NOYAFA NF-9816 Multi-Functional OTDR Instrument With Automatic OTDR, Expert OTDR, Event Map, 10G Split Wave Optical Power Meter, etc
Brand: NOYAFA 2.0
SKU: NF-9816
Price: 349.89 USD
Availability: InStock

NOYAFA NF-9816 Multi-Functional OTDR Instrument With Automatic OTDR, Expert OTDR, Event Map, 10G Split Wave Optical Power Meter, etc

$349.89 USD

Shipping calculated at checkout.

Style

NF-9816

NF-9816 *2

Beware of low-priced refurbished devices. Buy official.

30-Day Money Back Guarantee

In Stock, Fast Free Shipping

Buy more and save more

BUY OVER $300 USD for 8% OFF: Copy code BF300TEN
BUY OVER $600 USD for 10% OFF: Copy code BF600ELV
BUY OVER $1,000 USD for 12% OFF: Copy code BF1KTEW

Features & Benefits:

High-Precision Long-Distance Testing: Accurately diagnose fiber faults and measure performance over extended distances (up to 80 km) with a 22/20dB dynamic range, ensuring reliable network maintenance for telecom or enterprise applications.
Comprehensive Fiber Analysis: Quickly identify issues like breaks, bends, or splices through intelligent software analysis (Reflective/Reduce Events, Splitters, Fiber End), reducing troubleshooting time and improving repair efficiency.
User-Friendly Flexibility: Choose between Automatic OTDR for quick, one-click testing or Expert OTDR mode to customize parameters (wavelength, pulse duration), catering to both novices and professionals.
Safe and Non-Destructive Testing: High-isolation filtering technology protects sensitive optical components (e.g., transceivers) from damage during live network testing, ensuring operational safety.
Versatile LAN Troubleshooting: Diagnose common LAN cable faults (short circuits, open circuits, crosses) via Wire Mapping, streamlining network setup and maintenance for IT teams.
Accurate Cable Length Verification: Confirm cable installations meet specifications with 1–600m length testing, avoiding over-deployment or under-deployment in structured cabling projects.
Long-Lasting Portability: With a 4700mAh battery (6+ hours of continuous use) and Type-C charging, the device supports extended fieldwork without frequent recharging, ideal for remote locations.
Universal Connectivity: SC/PC or FC/PC interfaces ensure compatibility with most fiber networks, reducing the need for adapters and simplifying testing across diverse infrastructures.

OTDR

Wavelength: 1310/1550nm
Fiber Type: G.652 SM Fiber
Dynamic Range: 24dB/22dB
Event Blind Zone : 10m
ATT Blind Zone: 15m
Test Range: 10m-60km
Pulse Width: 5ns-10us
Ranging Accuracy: ±(1m+Sampling Interval+0.005%xTest Distance)
Loss Accuracy: ± 0.2dB/dB
Sampling Points: 16k-128k
Sampling Resolution: 0.05~8m
Reflection Accuracy: ±3dB
Data Storage: Internal: 2600: External: TF Card
Laser Safety Level: Class Il level
File Format: SOR Standard File Format
Connector: FC/PC (Interchangeable SC、ST)or FC/APC (Interchangeable SC, ST)

OPM

Wave Range: 800nm-1700nm
Interface Type: Universal Joint FC/SC/ST
Test Range: -50dBm~+26dBm
Uncertainty:+5%
Frequency Identification: CW/270/330/1k/2kHz
Calibration Wavelength: 850/1270/1300/1310/1490/1550/1577/1625nm

LS

LD Type: FPLD
Output Wavelength: 1310/1550nm
Output Power: 2-5dBm
Modulation Frequency: 270/330/1k/2kHz
Stability: CW,+0.5dB/15min (Test after15mins of preheating)
Connector: FC/PC (Interchangeable SCST) or FC/APC (lnterchangeable SC,ST)

VFL

Work Wavelength: 650nm土20nm
Output Power: 10mW
Mode: CW/1Hz/2Hz
Connector: FCISC/ST

Other Parameters

Dispaly: 3.5 inch Color LCD
Data Interface: Micro USB
External Storage: TF Card
Power Supply: Polymer Li-battery 3.7V, 4000mAh
Power Adapter: 5VDC, 2A
Battery Life: Standby>20h;
Measuring Time: >12h
Operating Temperature: -10°C~+50°C
Storage Temperature: -40°C~+70°C
Relative Humidity: 0~95%
Non Condensing Dimension: 173mmx82mmx37mm
Weight: ≤350g

NF-9816 OTDR comprehensive Tester User Manual

[{"id":50709622456595,"title":"NF-9816","option1":"NF-9816","option2":null,"option3":null,"sku":"NF-9816","requires_shipping":true,"taxable":false,"featured_image":null,"available":true,"name":"NOYAFA NF-9816 Multi-Functional OTDR  Instrument With Automatic OTDR, Expert OTDR, Event Map, 10G Split Wave Optical Power Meter, etc - NF-9816","public_title":"NF-9816","options":["NF-9816"],"price":34989,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":50709622489363,"title":"NF-9816 *2","option1":"NF-9816 *2","option2":null,"option3":null,"sku":"NF-9816 2PCS","requires_shipping":true,"taxable":false,"featured_image":null,"available":true,"name":"NOYAFA NF-9816 Multi-Functional OTDR  Instrument With Automatic OTDR, Expert OTDR, Event Map, 10G Split Wave Optical Power Meter, etc - NF-9816 *2","public_title":"NF-9816 *2","options":["NF-9816 *2"],"price":55019,"weight":0,"compare_at_price":69978,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]}]

NOYAFA

18 Years in Cable Testing and Tracing R&D and Manufacturing.

Our Story

A New Generation Of OTDR

Multifunctional Comprehensive Tester

Sixteen Core Functions

Split-wave power meter
Optical Power Meter
Automatic OTDR
Expert OTDR
Event Map
End State Check
RJ45 Cable Length
RJ45 Sequence
RJ45 Hunting
Multi-core Test
Wastage Test
Stabilized Light Source
Red Light Source
LED Light
End Surface Detection
Lithium Battery Charge

Automatic OTDR

Just set the measurement wavelength and test time, Other parameters are automatically selected by the instrument to complete the test

High Performance OTDR

The test distance reached an amazing 80km

Support 1310/1550nm dual-wavelength test

Expert OTDR

Expert mode: can manually adjust the test wavelength, range,pulse duration and other parameters

Event map intelligent link analysis

Automatic analysis of connectors, welding points, easy to read

End state check

Intelligent check the status of fiber optic network terminal resources, can not enter the household only in the corridor fiber box Determine the terminal connection status of the ONT line at the client end

Network cable sequence/ Length measurement/hunt

Support network cable sequence test, length measurement, line hunting, etc.

Three major network cable test functions

Network Scanning
Network cable Length
Line sequnence measurement

Strong red light Fast fault location

By injecting visible light (red light) into the fiber and observing the light leakage position on the measured fiber, the location of the fault point of the fiber can be easily and accurately determined.

4.3 inch multi-touch capacitive screen

Touch screen, button dual support, support new gesture amplification function, screen capture.

4700mAh lithium battery

Adopt mainstream TYPE-C charging interface, intelligent overcharge, overcurrent, overvoltage, short circuit protection.
